Varminpool空气源热泵泳池机 220v/60Hz 带 Wi-Fi 功能(变频15KW)

以下技术资料为英文原文。

SWIMMING POOL HEAT PUMP

MODEL KSPF-015L1VUA1

Power Supply 208-230V~ 60Hz

Waterproof Grade IPX4

Electrical Shockproof I

Max power input 10750Btu/h

Max current (A) 14 .5 A

Refrigerant type/quantity R32/22 .9 Ozs

GWP / CO2eq 675/0 .4388

Heating Capacity(80°FAir 80°F Water ) 12900~5 1180 Btu/ h

Power Input(80°F Air 80°F Water ) 850~8530 Btu/ h

COP(80°F Air 80°F Water ) 6.60~ 12 .50

Heating Capacity(60°FAir 80°F Water ) 10230~42650 Btu/ h

Power Input (60°F Air 80°F Water ) 1330~9400 Btu/ h

COP(60°F Air 80°F Water ) 4 .90~7 .60

Maximum working pressure of heat exchanger 4 .4 MPa

Maximum working pressure of exhaust side 2 .5MPa

Maximum working pressure of suction side 4 .4 MPa

Running (Air) temperature range 5℉~110℉

Water flow (gpm) 24 .0

Pressure loss of water side : 15 kPa

Noise 43~55 dB (A )

Net weight (lbs) 101

Dimension L *W * H ( inch) 36.2*15.0*25.6

Factory Number (On The Bar Code )

Manufactured Date (On The Bar Code )
